Description
The 150′ black Pro AV/IT Cat 6 Heavy-Duty Snagless Patch Cable from Comprehensive is rugged, durable, and engineered using pro grade 23 gauge twisted pair construction, that is then reinforced with a second heavy-duty PVC jacket making the cable useful for commercial applications of SMB, government, military, rental, and staging, and education. Snagless patch cable also provide up to 550 MHz bandwidth for high-speed signal transmission.
The cable meets all Cat 6 TIA/EIA standards. Each individual pair is attached together to ensure proper spacing between the twists of the wire which reduces loss, compared to a standard 100 MHz cable. It is suitable for distributing data, voice, and video on high-speed Ethernet and Gigabit networks and has molded, snagless boot that makes installing the cable quick and easy every time.
Additional information
| Weight | 6.2 lbs |
|---|---|
| Dimensions | 12.85 × 12.5 × 3.45 in |
| Length | 150.00' (45.72 m) |
| Connector Type 1 | RJ-45 male |
| Connector Type 2 | RJ-45 male |
| Gauge | 23 AWG |
| Bandwidth | Supports voice/data/video distribution applications up to 550 MHz |
| Conductors | 4 x Twisted pairs bare copper stranded cable |
| Connector Material | Polycarbonate |
| Cable Style | Molded snagless boot |
| Conductor DC Resistance | 9.8 ohm at 328' (100 m) maximum |
| Contact Material | Copper alloy plated with 50 u gold |
| Jacket | PVC |
| Standards | Meets all Cat 6 TIA/EIA standards <br> Verified to EIA/TIA 568B.2 |
| Compliance | RoHS |
